3pcs 42mm 12V Nema 17 Two Phase Stepper Motor For 3D Printer

3pcs 42mm 12V Nema 17 Two Phase Stepper Motor For 3D Printer

SKU: U2I-BG-1556469

Share this product

General Specifications
Step angle	1.8°
Number of phase	2
Insulation resistance	100MΩmin.(500V DC)
Insulation class	Class B
Rotor inertia	38g.cm²
Mass	0.2kg
Electrical Specifications
Rated voltage	12V
Rated current	1.7A
Resistance per phase	30Ω ± 10%
Inductance per phase	37mH ± 20%
Holding torque	260mN. m
Detent torque	12mN. m

Notes:
Due to the different production batch, the labels on the motor may vary but they are the same item, Thank you for your understanding!

Package Included:

3 x Stepper motor
