Features:●
This PCB board is black. Works on BLTouch or filament detection sensor. ● Improved design with wider power channels
● With this adapter, no wires need to be cut!! Simply connect this between your board and your cable, attach the 3 bltouch wires and upgrade your firmware.
●
BLTouch is not included with the Pin 27 Board● Compatible with: Ender 3/Ender 3 Pro/Ender 5/CR-10 Mini/CR-10. Incompatible with: ANet A8/CR-8
●
You must have a Bootloader flashed to your Ender 3 Board in order to use this.
Using Note:● Disconnect lcd ribbon ext1 on the control board
● Connect Ext1 to the pin 27 board
● Connect bltouch to the 3 pins on the pin 27 board. Left to right: Brown-Ground, Red-5v, Yellow-Signal
● Connect the pin27 to the main board. Make sure to align the header pins from the pin 27 to the main board.
Installation instructions: Click to know more
- Ender 3 marlin guide: Cllick (no loss of SDcard)
- Ender 3 marlin with bltouch: Click (no loss of SDcard)
Package Included:
1 x Black Creality CR-10/Ender 3 Pin 27
