Specification: 1. Brand: Ugreen
2. Model: MM103
3. Input interface: HDMI Male/ Micro USB
4. Output interface: VGA Female/3.5mm audio
5. Support Video output in VGA: 1920*1080@60Hz(Max)
Additonal power from Micro USB connector (for adapter with flat cable )
6. Version: HDMI 1.4
7. Cable Length: 16CM
8. Conductor: Pure Oxygen-Free Copper
9. Shell materal: ABS/ Aluminum
10. Cable shell material: PVC
11. OD: 5.0mm
12. IC: HP CB 0085
Features:
1.Built-in active IC chip converts HDMI digital signal to VGA analog signal ( HDMI-VGA )
The HDMI Male to VGA Female adapter supports resolutions up to 1920x1080 60Hz(Max), HDMI input resolution support: 480p,576p,720p,1080i,1080p
VGA output resolution support: 1024×768, 1280×720, 1280×768, 1280×800, 1280×1024, 1360×768, 1600×1200, 1920×1080
2.Wide Compatibility: HDMI to VGA converter adapts to laptop computer,camcorder and other device with HDMI port to VGA port adapts to projectors,
HDTV, monitors and other device with VGA
Note:
1.This adapter is not bi-directional, and can only support signal from HDMI source devices to VGA displays.
2.The micro USB cables included is required for MacBook Pro with Retina Display, Smart TV Box, Raspberry Pi,devices with low-power output HDMI port.
You can connect this micro USB cable to power adapter or USB port on your PC for additonal power.
3. For Raspberry Pi,you may need to revise the config.txt and reboot.
Package included:
1* Ugreen HDMI to VGA Converter
1* Micro USB Cable
1* Ugreen Box
