Specification:
Light source: 620mm visible red light diode
Image sensor: linear image sensor (CCD)
Resolution: 1500 pixels
Minimum contrast: ≥30%
Reading accuracy: ≥35mil
Reading code system: Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar, Interleaved2 of 5.ISBN Code 93. UCC/EAN-128 GS1 Databar, etc.
Scanning speed: 280 seconds
Tilt: ±55°
Rotation: ±25°
Deflection: ±75°
Data interface: FPC cable (bottom connection), spacing: 12*0.5m
Appearance size: 24-X21.35X6.0mm
Weight: (without wiring): 9g
Prompt mode: buzzer and LED indication
Maximum power consumption: 400mw
Working voltage: DCSv
Maximum current: 80mA
Working current: 74mA
Standby current: 24mA
Output signal: USB signal, RS232 (1T1L) signal
Storage temperature: -40 ° C ~ 60 ° C
Working temperature: 0°C-50°C
Relative humidity: 0-95% (no condensation)
The test strips are as follows:
Code 39, 3 Bytes; minimum prime width = 10mi, width to width ratio = 2.5:1; bar code height = 40mm: test distance = 180mm; ambient temperature = 25 ° C; ambient illumination = 200 LUXPackage includes:
1 * CCD Barcode Scan Engine
