Descripiton:
1. FT232 smart chip, RS232 interface, more versatile, more stable operation, lower power consumption.
2. Small size, the highest level of chip integration, with proprietary appearance patents, utility model patents and software copyrights. Passed CE, FCC, RoHS certification.
3. It is possible to read the error diagnosis code, clear the error code and turn off the MIL, and display the current sensor data, including the engine revolutions per minute, the calculated load value, and the coolant temperature.
Feature:
Model: V07HU
Communication Method: USB RS232
Master Chip: PIC 18F25K80
Working Voltage: 9-16V
Working Current: 65mA
Standby Current: 20mA
Working Temperature: -40-85 ° C
Working Humidity: Less Than 60%
Size: 41.8*19.7*31.7mm
Package Included:
1 X Scanner
