Specification:
Nominal impedance: 8 Ω
Nominal power: 10W
Sensitivity (2.83 V / 1 m): 88 dB
Frequency: 40-20 kHz
Diameter of voice coil 120mm
Width of voice coil: 108mm
Magnetic circuit, type: shielded magnetic circuit
Magnet material: high performance ferrite
Force coefficient (BL value): 6.5n / A
Height of the magnetic gap: 6.0mm
CIS: 857um / n
Mechanical Q value: 4.21
Electric Q value: 0.43
The total value of Q was 0.39
Size: 4.5”
Features:
1. Metal basin, good quality dynamic sound.
2. Long stroke, clear voice, stronger base for speaker subwoofer.
3. Four hole plate cooling, high power and more durable.
4. Rubber edge anti-aging and high temperature, without deformation.
5. Layered diaphragm, nicer sound performance.
6. Application of sound box update, DIY and what shape you want.
Package Included:
1 x Bass Horn
