Specification:
| Model |
1:TB4504 |
2:TB4505 |
3:TB4506 |
4:TB45010 |
5:TB45012 |
| Poles |
4 |
5 |
6 |
10 |
12 |
| Dimensions(mm) |
85*38*23.5 |
102.5*38*23.5 |
120.5*38*23.5 |
188*38*23.5 |
222*38*23.5 |
| Type |
TB Fixed terminal |
| Material |
H62 brass |
| Rated current |
45A |
| Rated voltage |
600V |
| Conductor cross section |
0.5-4mm2
|
| Number of pin |
8 |
|
Number of cores
|
4 |
| Contact material |
Brass |
| Insulation material |
Pc |
Feature:--PC protective cover, dustproof, durable
--All copper guides, strong electrical conductivity
--Color zinc plum screw, hard material, not easy to slide
--Flame-retardant shell, strong hardness, safe and reliable
Applications:
--High and low voltage complete sets of equipment, junction boxes, complete sets of cabinets, explosion-proof distribution boxes, explosion-proof junction boxes
Package Included:
1 x Fixed terminal
