40A 63A 230V Adjustable Digital Over Voltage Current and Under Voltage Protective Device Protector Relay Current Protection Limit
Feature:
Wide range of applications, stable and reliable quality, and automatic functions are used in mass-produced household appliances.
Specification:
Rated voltage: 220V Frequency: 50Hz/60HZ
Overcurrent protection: 1A-40A/63A (adjustable) (default: 20A)
Undervoltage action shutdown value: 210V-145V (adjustable) (default 160V)
Overvoltage action shutdown value: 230V-300V (adjustable) (default value: 280V)
Reconnect time (delayed on time): 1s-300s (default: 5s)
Real-time current and voltage error: 5%
Function:
1. Undervoltage protection 210V-140V (adjustable) (default: 160V)
2. Overvoltage protection 230V-300V (adjustable) (default 280V)
3. Overcurrent protection 1A-40A/63A (adjustable) (default 20A)
4. Reconnection time (delay start time): 1s-300s (default: 5s)
5. Voltmeter
6. Ammeter
Note:
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2cm measuring deviation due to manual measurement.
