AM2305 Digital Temperature and Humidity Sensor Capacitive Module High Precision Dust-proof Probe
Save 0
SKU: U2I-BG-1557346
Share this product
Description
Specification: Model: AM2305 Type: Digital Thermometer and Hygrometer Accuracy level: 0.1 Resolution: 0.1 Size: 99.9*16*16(mm) Weight: 0.077 kg Scope of application: Agricultural production, scientific research and education, industrial production, public service, health care, communication room Temperature measurement limit: - 40 ~+80 (℃) Humidity measurement limit: 0-99.9% (RH) Accuracy of temperature measurement: +-0.3 (℃) Temperature resolution: 0.1 (℃) accurate of humidity measurement: +-2%(RH) Humidity resolution: 0.1 (RH) Using Batteries: No Material: PC Plastics Output: Signal High Quality Digital Temperature and Humidity Sensor
Descripotion: AM2305 humidity sensitive capacitor digital temperature and humidity module is a temperature and humidity composite sensor which contains the output of calibrated digital signal. It uses special digital module acquisition technology and temperature and humidity sensing technology to ensure that the product has high reliability and excellent long-term stability. The sensor consists of a capacitive humidity sensor and a high-accurate NTC temperature sensor, which are connected with a high-performance 8-bit microcontroller. Therefore, the product has the advantages of excellent quality, ultra-quick response, strong anti-interference ability and high cost performance. Each sensor is calibrated in an extremely accurate humidity calibration laboratory. Calibration coefficients are stored in the form of program in the single chip computer. These calibration coefficients are called in the process of signal processing inside the sensor. Standard single bus interface makes system integration easy and quick. Ultra-small size, very low power consumption, signal transmission distance can reach more than 20 meters, making it the best choice for all kinds of applications and even the most demanding applications. The product is divided into 3 leads (single bus interface) and 4 leads, which are easy to connect and can freely choose any bus mode. Special encapsulation forms can be provided according to user needs.
