Product introduction:
This product adopts the latest BLDC brushless DC motor technology, the motor built-in brushless induction
Intelligent driver chip, quadrupole permanent magnet rotor drive.
Compared with similar products, it has low pressure safety.
Small size, high energy efficiency, smooth operation and so on.
The fuselage of the product is designed as non-metallic material, and the core of the shaft is high strength ceramic products, which can be immersed for a long time.
Soak in fresh water, sea water and light rotten liquid.
The product has the characteristics of high efficiency and low loss.
It has very low fever and can also be used as a land circulation pump in the air for a long time.
The product has a wide range of working voltage, which can realize variable voltage speed regulation and support direct drive of solar panels.
Applications:
Fish tank, aquarium equipment, aquaculture, landscape architecture, technological water circulation, industry and home
Electric water circulation.
Specifications:
Name: Water Pump
Model: SKD1000
Materials: ABS
Inlet/Outlet: φ17mm/ G3/8
Voltage: DC 9V~24V
Max Power: 10W
Max Flow Rate: 1000L/h
Max Water lift: 1.5 metre
Max circulating water temperature: 35℃
Noise: < 40 db (water) under operation
Drive mode: electromagnetic
Conveying medium: Cold Water Pump
Pump shaft position: horizontal
Impeller structure: open impeller
Impeller suction method: single suction type
Cable line: 110cm
Sizes:About 10cm(L) x 8cm(W) x 8cm(H)
Package included:
1 x Brushless Motor Water Pump
