Specification
Material: ABS
Color: Black
Input voltage : Type-C/Micro DC 5V 2A
Output Voltage :4.35±0.1%/4.2V±0.1%/1.48V±0.1% 9V(6F22) ±0.1%
Output Current: Li-ion: 1000mA*2(High)/500mA*4(Low)
Ni-MH/Ni-Cd: 1000mA*2(High)/500mA*4(Low)
9V(6F22):100mA*3
Compatible with:
Li-ion/IMR/INR/ICR/LiFePO4:
10340,10350,10440,10500,12340,12500,12650,13450,13500,13650,14350,14430,14500,14650,16500,16340(RCR123), 16650, 17350,17500,17650,17670,1350,18490,18500,18650,18700,20700,22500,22650,25500,26500,26650 9V(6F22)
NI-MH/Ni-Cd: AA, AAA, AAAA, C 9V(6F22)
Size: 126.6mm*97mm*33mm(L*W*H)
Features
* Excellent circuit design
* Detect battery capacity in charger
* Designed by optimal heat dissipation
* Support small capacity battery charging
* Support for lithium battery repair function
* Up to 1000mA charging speed I a single slot
* High precision Calibration of voltage source
* Each battery slot controls and charges independently
* Automatically stops charging upon charging completion
* Reverse polarity protection and short circuit prevention
* Compatible with DC Type-C,Micro Charging function Made of fire
* Automatically detects battery power status and displays charging progress
* Compatible with all different type of cylindrical rechargeable lithium battery
* Compatible with batteries of Li-ion(4.2v/4.35v) 9V(6F22) LiFePO4(3.6v),Ni-MH/Ni-Cd(1.48v) 9V(6F22)
Operating Instructions
Connect one side of cable to Charger, the other side to DC 5V 2A charger. When the power is on, LCD back-light will shine, and the charger will automatically detect the power condition, meanwhile LCD will show all the data, 3 second later, LCD will show NULL and the 3 9V symbols.
Install Battery
Charger has 4+3 charging slots, each charging slot controlled independently, support single battery charging mode, mixed battery charging mode, User can put different type battery into slots with the correct polarity position according to the marking.
Package included:
1 X Li Battery Charger (battery not included)
1 X USB Cable
1 X English Manual
