Parameter:
Working voltage: 110V-250V
Rated power: 200W
Induction angle: 110-140 degrees (directly related to installation)
Delay time: 20s-6 minutes, adjustable
Sensing distance: 0-5m (directly related to installation)
Name |
Parameter |
PCB mark |
Quantity |
0603 SMD resistor |
10K |
R1, R3, R16 |
3 |
1K |
R24 |
1 |
2K |
R21 |
1 |
100K |
R25 |
1 |
4.7K |
R10 |
1 |
6.8K |
R13 |
1 |
15K |
R23 |
1 |
47K |
R2, R5, R203 |
|
18K |
R6, R14 |
2 |
1M |
R8, R15 |
2 |
2.2M |
R7, R9, R11 |
3 |
0805 SMD resistor |
1.2M |
R18 |
1 |
1.5M |
R19 |
1 |
10K |
RT |
1 |
SMD diode |
1N4148 |
DH3, DH5 |
2 |
M7 |
DH4 |
1 |
SMD Zener diode |
6.8V |
DH1, DH2 |
2 |
SMD capacitor |
103 |
C3, C4, C5, C8, C10, C13, C14 |
7 |
683 |
C6, C7, CH3 |
3 |
Toggle switch |
|
K |
1 |
Integrated circuit |
7533 |
U1 |
1 |
BISS0001 |
U2 |
1 |
Horizontal potentiometer |
1M |
WL |
1 |
204 |
WT |
1 |
Electrolytic capacitor |
47uF |
C2, C9, C11 |
3 |
22uF |
C12 |
1 |
High voltage capacitor |
221/1kw |
CH1 |
1 |
103/1kw |
CH2 |
1 |
Ballast bridge |
KBP206 |
DDF |
1 |
SCR |
MCR100-8 |
Q1 |
1 |
BTB04600SL |
Q2 |
1 |
Fuse |
|
F1 |
1 |
Infrared sensor head |
|
|
1 |
Lens |
|
|
1 |
Package included:
1 x DIY Human Body Sensor Switch Electronic Production Kit
