Description:
Kit Name: SMD Round Sound Control Light Kit
Board size: 45*45mm
Board material: single side 1.6mm FR-4
Supply voltage: 5V
Number of LEDs: 2 x 5mm LEDs
LED color: red
Name |
Parameter |
PCB mark |
Quantity |
0805 SMD resistor |
1K |
R1,R8 |
2 |
1M |
R4 |
1 |
2M |
R2 |
1 |
4.7K |
R7 |
1 |
10K |
R3,R6 |
2 |
510K |
R9 |
1 |
SMD electrolytic capacitor |
100uF |
C5 |
1 |
Electret microphone |
|
MK1 |
1 |
SMD capacitor |
103 |
C4 |
1 |
104 |
C2,C3 |
2 |
SMD integrated circuit |
NE555 |
IC1 |
1 |
SMD transistor SOT-23 |
8050 |
VT1,VT2 |
2 |
Terminal |
2p |
J1 |
1 |
SMD diode Do-214 |
1N4007 |
VD1 |
1 |
SMD LED 0805 |
Red |
5V LED2 |
1 |
PCB |
|
|
1 |
Package included:
1 x DIY SMD Round Sound Control LED Light Electronic Kit
