Name: HV-1 high-pressure igniter (DIY kit, you need to assemble it)
Input voltage: DC3-5V
Input current: 3A
Operating current: no less than 2.5A
Working mode: self-excited oscillation boost
Working frequency: about 20KHz
Continuous working time: 10 seconds
Arc length: about 5 mm
Size: 71 x 18 x 12mm (L x W x H)
Ignition switch: yes
Weight: 15 g
List:
| NO. |
Component Name |
PCB Marker |
Parameter |
QTY |
| 1 |
Carbon film resistors |
R1 |
33R/1W |
1 |
| 2 |
Electrolytic capacitor |
C1 |
470UF |
1 |
| 3 |
Diode |
D1 |
1N5819 |
1 |
| 4 |
Button |
SW1 |
6*6*5mm |
1 |
| 5 |
Transistor |
Q1 |
D880 |
1 |
| 6 |
Battery terminal |
JK1 |
KF301-2P |
1 |
| 7 |
Transformer |
T1 |
14*15*8 |
1 |
| 8 |
PCB |
-- |
18*71mm |
1 |
| 9 |
Screw |
Q1 |
M3*5 |
1 |
| 10 |
Nut |
Q1 |
M3 |
1 |
| 11 |
Tie |
T1 |
3*100mm |
1 |
Package includes:
1 x Arc Ignition Lighter Kit
After assemble, for reference only
,,,,,
