| Product name: |
LiitoKala Lii-300 1.2V/3.7V Battery Charger |
| Brand: |
LiitoKala |
| Model: |
Lii-300 |
| DC Input voltage: |
12V/1.5A |
| Li-ion battery charging current: |
4.2±0.05V |
| NiMH battery charging current: |
1.42v |
| Compatible Batteries: |
18650,26650,14500, AA, AAA, etc.(not included) |
| Cut-off current: |
< 100 mA |
| Converter standby current: |
< 15.0 mA |
| Weight: |
120g+100g+32g |
| Size: |
140mm(L) x 68mm(W) x 32mm(H) |
Features:1. More charge current regulation (500mA / 1000mA)
2. It can be of different size batteries while charging(18650/26650……/AA/AAA)
3. Variety of display modes,voltage (V) Current (mA) Time (h) Capacity (mAh) resistance (mR)
4. Each independent LCD display battery charging parameters;
5. Have 0 V voltage activation function
6. Discharger mode (first discharging and then fully charge), detection of battery capacity.
7. Each cell can be set simultaneously charge / discharge function, and a separate set charge / discharge function
8. The charger has two button, control the charging current, easy to use current button. Hold down the select key under any circumstances and keep 3 seconds gently press the select key change the charging mode and discharging mode, 8 seconds after selected need to have current into the charging status.
The USB output parameters:
1, the USB port output no-load voltage: 4.90-5.30 V.
2, the output current: 1000 mA;
3, no-load current: < 1 m A;
4, 1000 m - A load current, the port output voltage: 4.80-5.25 V.
5, stop output voltage protection: 3.0 + / - 0.1 V.
Warning:
1. The charger can only cylindrical lithium-ion batteries, and compatible with nimh batteries;
2. Before use, please refer to the instructions carefully, pay attention to the rechargeable battery choice;
3. Do not use other power adapter;
4. Only can be used in normal indoor.
5. Stop the use, please unplug the power
Package included:1 X LiitoKala Lii-400 1.2V/3.7V Battery Charger
1 X 1.5A adapter
1 x Car charger
