Item Name: Ultrasonic Solar Powered Cat Dog Repelle Animal Chaser Deterrent Repellent Newly. Smart TV Box Android Quad Core HDMI 1080P Wifi Streaming Media Player UK
Specifications:
Voltage: 1.2v
Rated Frequency: 4V / 45MA (HZ)
Ultrasonic Frequency: 25kHz
Size(mm): 440*110*50mm/17.16*4.29*1.95"
Speakers: Emit ultrasonic sound to repel pests
PIR Motion Detector: Detects movement in the area being protected
Operation:
-A strong ultrasonic wave to frighten animals
The wave's activated when an animal enters the PIR Sensor range and then animals feel uncomfortable and will run away from the area.
-A strong flashing white-LED to scare animals
The strong flashing white-LED will be activated when an animal enters the area, then animal will be scared and flee away
SET UP:
- Button "Sensitivity" (Right):You can adjust the item frequency. By turning the knob clockwise, the frequency will be increased.
- Button "Frequency" (Left):This is to control frequency.By turning the knob clockwise, you increase the range of protection.
Button "Frequency" position as below:
- 0:OFF
- 1: 13.5KHZ-20KHZ to repel animals such as mice, rats, dogs, foxes,martens etc.
- 2: 15.5KHZ-25KHZ to repel animals such as cats, raccoons,badgers, skunks etc.
- 3: 25KHZ-34.5KHZ to repel animals such as bats, birds, rodents etc.
- 4: strong flashing lights to repel animals such as raccoon, boar, marten etc.
- 5: 13.5-KHZ-40KHZ to repel all animals above, and turn on strong flashing
To Assemble and Install:
1. Remove the battery compartment on the back: Install 4XAA size rechargeable batteries, and then close the battery compartment, (battery included, so do not need this)
2. Place the unit pointed towards the area that you want to protect(for example,in the flowerbed or against the wall etc.)
3. Remember to choose a place where the solar panel of the top can get as long time sunshine as possible.
4. If you mount the unit in the ground, insert the spike into the ground carefully. (See Figure 2to connect the pole sections.) please leave the spoke 12cm or more above the ground. (see Figure 2) It is suggested that you dig a hole and then insert the unit to ensure no damage occurs.
5. The item can be inserted in the ground or mounted against the wall, or put the top part directly on the flat surface.
Technical Specification:
Infrared sensor angle: 110 degrees
Detection range: 6-8 meters depending on animals size (the bigger size, the larger range)
Power supply: solar power 4XAA size Ni-MH rechargeable batteries
If adapter plugged, the item will keep working, the PIR sensor will not work
It there are a few days as cloudy or rainy, you must charge the batteries as long time sunshine as possible
Red LED: indicates the unit is activated
Battery issue:
1. If new rechargeable batteries or batteries in the product no use for a long time (more than 1 month), the batteries power may be fully released. It is suggested to charge the batteries 3-5 times to activate and they will become normal to use.
2. If the batteries which have been used for a very long time can be charged fully very soon, it means you need to change the batteries.
3. If the battery cannot be use for a long time, please replace 4 pieces 1.2V AA size rechargeable batteries (NiCad or Ni-MH ) in the battery compartment, The better quality the batteries are, the bigger capacity the batteries are and the better effect the item will be.
4. Please deal with the abandoned batteries to the recycling center for the used electrical and electronic devices, You can consult the local government for more information.
Caution:
1.It happens that human can hear part of its range. So put the device as far as possible from human life place. Do not install the device in a children and baby playing ground area.
2. Do not cover up the PIR sensor.
3. To clean the device, use damp-soft and mild soap with water. Do not use harsh chemicals or abrasive cleaning agents that may the device.
