ITEM NAME:15A 500W Dc12V-36V Brushless Motor Speed Controller Bldc Driver Board With HY8Q5 15A 500W Dc12V-36V Brushless Motor Speed Controller Bldc Driver Board With HY8Q5 Tips:If you use less than 60W,without additional heat sink;please make sure to add heatsink when exceed 60W.The size of the heat sink may be a bad environment based work(recommended cooling surface area greater than 200 square centimeters)!When installing the heat sink,must pay attention to the back of the module 6 MOS pipe insulation, no insulation,it will be adhered to drive plate permanently damaged! Proposes to add insulation films,both sides of the insulating sheet plus thermal grease! Hall signal inputs:Wiring diagram is shown,one corresponding to the HA,HB,HC and on the motor,5V power supply connected to the motor hall signals positive,GND power supply negative signal to the motor hall. Wiring:Control terminal for SET:1. The motor speed control wiring methods: available potentiometer system speed can also be connected to the MCU control, when the potentiometer control wiring, the potentiometer middle pin is connected to VR speed port, potentiometer connected to both ends of 5V and GND terminal voltage more high speed faster. 2. Motor steering control wiring methods: you can switch control can also be connected to the MCU control, to GND in one direction, then in one direction 5V.3. Pulse speed signal: high and low output. IC can not understand the information with the customer request. Note: Due to different motor manufacturers to make the hall line order does not necessarily follow the line on the board to match the sequence, which needs to be adjusted, please pay attention! If the line sequence wrong, does not boot properly, current, or start other phenomena not open, forced to use the drive plate will burn! Operating Voltage:DC12-36V Operating Current:less than equal 15A Drive Power:less than equal 500W Speed Voltage:0.1V-5V Operating Temperature:-40~85 Celsius Humidity:less than equal 9.Drive Power:less than equal 500W. Pulse speed signal: high and low output. Proposes to add insulation films,both sides of the insulating sheet plus thermal grease!
