Item Name: KB-075C 433MHz Copy Remote Controller 4 Buttons Garage Key (A Type Lock). Smart TV Box Android Quad Core HDMI 1080P Wifi Streaming Media Player UK
KB-075C Universal Copy Remote Controller 4 Buttons Garage Gate Door Opener Duplicator Clone Cloning Learning Code Car Key
Feature:
Using high-performance radio frequency chip, crystal oscillator frequency stabilization, accurate frequency point
Long transmission distance, no directionality, high transmission sensitivity, no signal blocking
It can copy most of the fixed code and learning code wireless remote control, the copy speed is fast, and the operation is simple
After copying, it will not affect the original remote control
Copy code automatically, use directly, no coding required
Range of use: duplication and regeneration of wireless remote controls such as barriers, garage doors, cars/motorcycles, etc.
The scope of application of the copy remote control: ordinary fixed code (chip type 2260, 2262, 2264), learning code (1527, 2240) remote control.
Specification:
Type: Wireless remote control
Model: KB-075C belt buckle
Material: ABS
Color: Black
Button: A - Lock type/B - ABCD (optional)
Number of buttons: 4
Rated voltage: 12V
Wireless transmission distance: 50-150 (m) (open space)
Working voltage: DC 12V
Working current: 14mA
Quiescent current: 0mA
Working frequency: 315/433MHz (optional)
Launch distance: 100m (open environment)
Size: 90x60x13mm/3.54x2.36x0.51in
Weight: 25g
Operation method:
1. Code pairing (learning)
Place the original remote control and the copy remote control as close as possible, first press a button of the original remote control, and then press a button of the self-copy remote control immediately after the indicator light turns on for about three seconds, the LED will flash 3 times and then quickly Flashing, it means that the address code of the original remote control button has been learned successfully. The other keys are operated in the same way for learning.
2. Clear code
Press the unlock button and the lock button at the same time for 2 seconds, the LED light starts to flash 3 times. At this time, keep the lock button pressed and release the unlock button. Press the unlock button three or four times within 5 seconds, and the indicator light flashes quickly. The code has been cleared.
Test whether the existing code of the remote control has been successfully cleared: When you finish the clearing action, you can press any button of the copy remote control. If the LED does not flash immediately at this time, it will flash after 2 seconds, that means Copy the original code of the remote control has been completely cleared, if the LED still flashes quickly, it means that the code still exists and needs to be cleared again.
3. Restore the cleared code
The copy remote control has a recovery function. If you accidentally clear the address code of the normal copy remote control during use, you can press the start and mute buttons (the next two buttons) on the remote control at the same time. After about three seconds, the LED will flash 3 times. It starts to flash quickly, which means that the cleared address code is successfully restored.
Note:
Before using our copy remote control to copy, first clear the existing code of the self-copy remote control.
The self-copy remote control cannot copy the rolling code, such as HCS301.
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2cm measuring deviation due to manual measurement.
