Mini 12A 144W RGB LED Amplifier For SMD5050/3528 Strip Light DC12V

Features:
Mini amplifier is applied to all of the Voltage-controlled LED controller. It accepts PWM(Pulse width modulation)
Each additional amplifier will double the quantity of the led to be connected.Theoretically, it can connect various RGB amplifier.

Specification:
Model:Mini RGB amplifier
Working Voltage:DC12V
Max Output Wattage:144W
Max Output Current:3*4A <2.5A(each circuit)
Working Temperature:-20°C- 60°C
Static Consumption of Wattage:<0.5 W
Material:ABS
Dimension:L40*W12*H5(mm)
Connect Mode:Common Anode
Connect Type:4Pin Connector
Output:3 Circuit

Package Included:
1X Mini RGB Color LED Amplifier
