Product characteristics:
1. Start up and check battery voltage
2. Support bluetooth Handsfree, built-in microphone, convenient and safe to answer calls; call display
3. CVC, wind noise suppression, full duplex call technology;
4. Support A2DP function of mobile phone, and play high-quality mobile music directly after connecting bluetooth;
5. Automatically connect back after power on and start up, and automatically enter the pairing state;
6. Support the expansion of tfcard to play MP3 / wma music;
7. It is equipped with a car charger, with an output of 5v-2100m, which can charge the handheld terminal equipment.
8. Output and input of AVX port. Song name display
Operation instructions:
1.Boot up
(1) insert the device into the vehicle lighting power socket, and it will start automatically after power on;
(2) select a transmission frequency point on the equipment through adjustment;
(3) turn on the car audio and put it in FM radio state, and adjust the receiving frequency of car radio to be consistent with the transmitting frequency of the equipment.
2. Adjust the frequency and volume
(1) the equipment supports full frequency point transmission, frequency range: 87.5mhz-108.0mhz. You can enter the frequency point adjustment mode by pressing the frequency point option key briefly, use the up and down direction keys to adjust to the required transmission frequency, and then press the frequency point option key to confirm the frequency point.
(2) adjust the transmitting volume: in the music playing mode or call mode, long press the up and down direction keys to adjust the volume.
(3) song selection: short press direction keys "" and "" to select the track to be played;
3. Play music in tfcard
(1) insert the tfcard into the tfcard expansion slot of the device, and the device will automatically recognize and play MP3 / wma music files in the tfcard.
(2) play / pause: in the music playing state, short press "" key to switch between music playing and pause.
(3) song selection: in the playing state, short press "" and "" to select songs.
4. Connect Bluetooth device
(1) the device is equipped with a bluetooth chip, which can be connected with a hand-held Bluetooth device.
(2) after the device is powered on, it will automatically enter the Bluetooth pairing status. At this time, the Bluetooth indicator is flashing at the frequency of 1 time / second. At this time, use the Bluetooth of the handheld terminal device to search for the Bluetooth named "T6" to connect;
(3) the device has memory function. After pairing connection, it will be automatically connected after startup, without manual connection again;
(4) if you need to disconnect the currently connected Bluetooth device, you can press "" for a long time to disconnect the currently connected Bluetooth device, or you can disconnect Bluetooth at the Bluetooth device end.
5. Play music in mobile phone
(1) after Bluetooth is connected, you can play music with your mobile phone and transmit it to the car audio via wireless.
(2) you can control the music through the operation of mobile phone, as well as the volume of music, the play / pause of songs, and the selection of the previous / next music.
6. Switch music source
(1) the device can play the music of tfcard or Bluetooth device. If both exist, you can switch between them by long pressing "" key.
7. Call
(1) after bluetooth connection, you can use this device and mobile phone to make and receive calls.
(2) double click to redial the group of calls dialed later.
(3) switch the call device: in the call state, long press to switch between the Bluetooth Handsfree device and the handset quickly.
Technical parameters:
Brand: Bakeey
Color: Black
Input voltage: 12-24V
Output voltage: 5 V + / -- 0.25
Output current: 1000mA Max
Short circuit protection current: 2.4 - 3 A
bluetooth version: V3.0 + EDR
Frequency: 20 h ~ 20 kHz
Sensitivity: - 42 DB + / 3 dB 360
Voltage: 5 V + / - 0.5
Working current: 45mA (large)
Standby current: 25mA (large)
Frequency: 2.402 ~ 2.480 GHz
Effective distance: 5m
Sensitivity: - 92 dBm
RF output: 4 dBm
Frequency: 87.5mhz-108.0MHz
Transmitting power: 87 dBuV / 107 dBuV
Effective distance: 2m
Package Includes:
1* Car Charger
