Description:
This is a complete DDS signal source, Adopts DC5V power supply, can output the sine wave, square wave (Duty cycle Can be adjusted from1% -99%), triangle wave and sawtooth wave and various function waveform, maximum output can reach up to 10 Vpp, frequency range from 0.01 Hz-2 MHz. Resolution for 10 MHz, with TTL synchronization output and 60 MHz frequency meter.
Specifications:
* MAX Frequency: 5MHz
* Wave form: Sine wave, square wave, triangle wave and sawtooth wave
* Max output: 10Vpp(no-load)
* Otput Resistance: 50Ω±10%
* DC bias: ±2.5V
* Duty cycle: 1%-99%
* Display: LCD1602
* Output frequency range:
* sine wave: 0.01Hz-5MHz
* Square-wave: 0.01 Hz - 1MHz (the valid range)
* Triangle wave: 0.01 Hz - 1MHz (the valid range)
* Sawtooth wave: 0.01 Hz ~ 1MHz (the valid range)
* Resolution: 0.01 Hz
* Frequency stability: + 1 x 10-6
* Frequency error: + 5 x 10-6
* Sine wave distortion degree: < 0.8% (benchmark frequency 1kHz)
* Triangle wave linearity: 0.01 Hz ~ 10KHZ 98%; 95%, 10 KHZ ~ 1MHz;
* Square-wave rising and falling time: < 100ns
* TTL output: TTL level: Vp - p. 3 p, Take 20TTL load load capacity
* The external measurement functions:
* Frequency range: 60MHz~1Hz
* Vpp - signal amplitude: 0.5 20Vpp
* Storage and append the: has 10 groups with v function parameters storage
Package includes:
1 x DDS Function Signal Generator
1 x 5V Power Supply
