Specificatons:
Input voltage: 7-30V DC
Quiescent current: 4mA
Maximum power consumption: 75mA
Relay load capacity: 250V 10A AC/30V 10A DC
Control mode: automatic cycle and trigger cycle
Size: 100x47x29mm
Features:
1 Adopt advanced high-quality timing chip control, accurate timing;
2 Use high-power relay to control the load, up to 10A;
3 The relay is turned on and off and the potentiometer is adjustable.
4 delay has potentiometer adjustment, the longer the clockwise adjustment time will be;
5 with a delay switch indication;
6 relay output has normally open and normally closed interface
Applications:
Application:
The module is energized, the relay is simultaneously closed, then disconnected, and the cycle is repeated. It is often used in machine cycle start, stop, product life test, component life test, automation equipment control, PLC control, electronic experiment, etc.
Package Included:
1 x Cycle Timer Switch Relay
