| Hardware Structure |
MSTAR MC316DM + 400-megapixel 1/3" CMOS OV4689-2A |
| Minimum Illumination |
Color 0.05 Lux@F1.2, black and white 0.01 Lux@F1.2 |
| Wide Dynamic Range |
Digital Wide Dynamic |
| Signal to Noise Ratio |
≥39dB |
| Image Quality |
Saturation setting, contrast setting, sharpness setting, brightness setting, auto white balance, manual white balance setting, backlight compensation setting, strong light suppression setting, auto exposure, 2D/3D noise reduction intensity setting, fog setting , WDR mode strength settings |
| Video Features |
Masking, OSD Character Overlay, Motion Detection |
| Interface |
Audio linear input and output. |
| Coding Format |
H.264 Main Profile/High Profile |
| H.265/HEVC Main Profile/High Profile |
| Image Resolution |
4 million main stream: 2688*1520, 1-20 frames/second |
| 3 million main stream: 2304*1296, 1-25 frames/second |
| 2 million main stream: 1920*1080, 1-25 frames/second |
| 1.0 million main stream: 1280*720, 1-25 frames/sec. |
| Image Mode |
Horizontal flip and vertical flip |
| Video Compression Rate |
32Kbps-5Mbps continuously adjustable, support CBR / VBR |
| Audio Code |
G.711/AAC audio codec standard, support two-way voice intercom function, support audio and video synchronization |
| Network Interface |
10/100M adaptive Ethernet interface, lightning protection design |
| Protocol Support |
Supports HTTP/RTSP/FTP/PPPOE/DHCP/DDNS/NTP/ONVIF/P2P network protocols |
| Digital Storage |
Not support |
| Mobile Client |
Support Windows Mobile, i Phone, iPad, Android platform |
| Dimensions |
38 x 38 x 15mm |
| Weight |
60g |
| Power |
DC12V/POE, 1.2W max. |
