AC110V/220V to DC24V 10A 250W Switching Power Supply without Fan 200*110*50mm

AC110V/220V to DC24V 10A 250W Switching Power Supply without Fan 20011050mm

Name: AC110V/220V to DC24V 10A 250W Switching Power Supply without Fan 200*110*50mm
Brand: Banggood
SKU: U2I-BG-1528280
Price: 6,332.00 INR
Availability: InStock

SKU: U2I-BG-1528280

Share this product

Feature:

Project	Technical indicators	Unit	Remarks
Basic requirements	24V 10A 250W	1	Normal (no fan)
Dimensions	20011050	mm
Operating temperature	-10 ° C ~ +50 ° C, 20% ~ 95% RH (no condensation)	℃
Storage temperature	-20 ° C ~ +85 ° C, 20% ~ 95% RH (no condensation)	℃
Temperature Coefficient	0.02~0.05%/°C
Heat dissipation method	Natural cooling
Rated voltage range	220VAC	V	AC
Input voltage range	110V/220V	V	AC
Input frequency range	50 to 60 Hz	Hz	Except DC input
Input undervoltage protection	115 to 150% intermittent mode	V
Input undervoltage recovery	Automatic recovery	V
Input overvoltage protection	115 to 150% intermittent mode	V
Input overvoltage recovery	Automatic recovery	V
electric shock	≤1%	A	Maximum input voltage full load
Machine efficiency	≤0.5%	%	Rated input full load
Output voltage range	24V ± 0.5%	V	Triple output
Output current	10A	A	Triple output
Ripple and noise	≤150	mVp-p
Rise Time	≤50	ms
Output delay	≤5	S
Voltage regulation	≤0.5	%
Load adjustment rate	≤1%	%
Output overcurrent protection	Current drooping
Output short circuit protection	IGBT
Output overvoltage protection	Soft start protection
Insulation resistance input to output	>30MΩ
Insulation resistance input to the earth	>30MΩ
Insulation resistance output to the earth	>30MΩ
Insulation resistance	>50MΩ
MTBF	100,000	H
Annual repair rate	0.3<	%

Package includes:

1 x Power supply
