Product Highlights:
1. Synchronous rectification scheme, wide voltage, high current, high efficiency;
2. With terminal block and DC plug, it is very convenient to use;
3. 4 USB ports, all with fast charging identification chip compatible with Android iphone
4. With a beautiful aluminum casing, easy to use.
Parameters:
Working voltage: DC 9V--36V;
With input reverse connection protection, output short circuit protection;
Output voltage: 5.2V/5A/25W (total output current of 4 ports)
Output capacity:
9~24V input: Output 5.2V/6A/30W
24~32V input: output 5.2V/5A/25W
32~36V input: output 5.2V/3.5A/18W
Size: 70*40*30MM (length * width * height)
Weight: 57gNote:
It is not that the power module has 5A current, and there will be 5A current to charge the phone. The magnitude of the charging current is determined by the power supply IC inside the phone.
Package includes:
1 x Power supply module
