Item Name: CF Compact Card to 2.5" 44Pins IDE Hard Drive Converter Adapter For Laptop K7Q2. Product description:
Features:
Support for a single CF card type.
For laptops, convert your CF card to a standard IDE hard drive.
For embedded industrial PC, used to store embedded LINUX, WINCE and other operating systems and applications data.
You can also plug directly into the laptop IDE port. Easy to use.
CF card to 44PIN 2.5 "IDE hard drive.
IDE CF (ide-cf) adapters are adapters that connect compact CARDS to the 2.5-inch host interface. This drive allows the use of compact CARDS as hard disk ides. The adapter allows any computer with a 2.5-inch hard disk to easily convert to using low-power and shock-resistant CF media.
Specifications:
Single CF card type I/II is supported.
No driver is required
Master/slave selection mode
Male 44 pin IDE connector.
You can use CF to boot from /Windows/Linux, even as an IDE hard drive, but using DMA MOD from the main/slave jumper is faster
Type :CF to 2.5 "44 pin IDE hard drive
Material: PCB
Interface: 44 pin
Size: approximately 53 * 44 * 5 mm / 2.1 * 1.7 * 0.2 in
Weight: 5 grams
Package package:
1 x CF for 44 PCB adapter
