Features:
1.Iron plated tip and stainless steel construction offer longer steel construction offer longer life.
2.Whether you need to repair electronic equipment, RC toys, circuit boards, or simply want to be creative, this complete set will allow any project to be finished quickly and easily.
Specification:
Soldering Iron Length: Approx. 22 cm
Cable Length: Approx.80cm
Working Voltage: 110 V
Power: 60W
Adjustable temperature: 200℃-450℃
How to solder:
1.Clean the parts to be joined.
2.Clean soldering iron tip and "tin" all faces of tip with a coating of solder.
3.Heat parts , not solder, to be joined.
4.Apply solder to heated parts, not the soldering tip, and heat it till solder melts and flows freely.
How to Replace the Soldering Tips:
1.Unscrew the screw with pliers counterclockwise
2.Remove the tip which is to be replaced
3.Put on a new tip
4.Tighten the screw clockwise
Caution:
1.When the soldering iron is plugged in for the first time, there comes out a smoke from the tip end. The smoke stops in a smoke while and a smoke never comes out again.
2.Use soldering stand and other aids to avoid bur fingers.
3.Don't pull the soldering and other aids to avoid burnt fingers.
4.After finish the longer life tip face
5.Don't file the long life tip face.
6.Don't apply too much solder unnecessarily.
Package Included:
1 x Temperature Adjust Soldering Iron
5 x Soldering Iron Tips
1 x Soldering Stand
1 x Solder Wire
1 x Anti-static Tweezers
Detail Pictures:
