Item Name: #A 050 Bushed Motor 30A Bushed ESC Kits for 1/24 RC Crawler Axial SCX24 AXI00002. Smart TV Box Android Quad Core HDMI 1080P Wifi Streaming Media Player UK
050 50T/66T Bushed Motor Mini 30A Bushed ESC for 1/24 RC Crawler Axial SCX24 AXI90081 AXI00001 AXI00002 Upgrade Parts
Feature:
1. High-purity copper winding can maximize efficiency, excellent setting, acceleration and linear characteristics, strong current resistance, and good heat dissipation. The ESC has its own overheat protection, if the motor is overheated, the ESC will adjust the output voltage.
2. Sturdy and durable: Made of sturdy, high-quality materials, the remote control lasts for a long time.
3. Excellent torque and long running time. Direct solder lugs for flexible soldering options.
4. Precisely balanced rotor, smoothness can achieve the best reliability and maximum speed.
5. Suitable for 1/24 RC Crawler Axial SCX24 AXI90081 AXI00001 AXI00002 RC Car, Boat Upgrade Parts, etc.
Specification:
050 brushed motor:
Number of turns: 66T
Weight: 19g
Rated voltage: 7.4V
Overall length: 28.5mm/1.12"
Output shaft length: 6.6mm / 0.26 inches
Output shaft outer diameter: 1.5mm / 0.06 inches
Number of turns: 50T
Weight: 19g
Rated voltage: 7.4V
Overall Length: 28.5mm/1.12"
Output shaft length: 4.9mm / 0.19in
Outer diameter of output shaft: 1.5mm / 0.06in
30A Brushed ESC:
Function: Forward, reverse, brake
Voltage: 4.8V-9.4V
Dimensions: 35.0x22.0x6.0mm/1.38x0.87x0.24in
Current: 30A
Driving frequency: 2KHz
Input: Li-Po 2S / Ni-Mh/Ni-cd 4-7cell
Constant current 20A Max 25A less than 30s Pulse 50A less than 5s
Material: Composite
Colour: Black
Note:
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2mm measuring deviation due to manual measurement.
