Note: This product is suitable use for Product ID: 1038472, Product ID: 1084465, Product ID: 1129370Feature:DC output voltage: 36V
Maximum output current: 20A
Maximum output power: 720W
Voltage adjustment range: 0-36V
Current adjustment range: Current is not adjustable
Voltage regulation: External knob potentiometer voltage
Power conversion efficiency: 85%
Output voltage accuracy: ±1%
Cooling mode: High speed dual-ball cooling fan (the wind is blowing inside but also be changed to ventilation)
Input voltage: AC 200V - 250V
Power on impact current: 4-6A/AC220V
Leakage current: <= 3.5ma / 220V AC
Overvoltage protection: maximum output voltage 115% -135% cut off the output, after normal recovery output
Overload protection: the maximum output power of 105% -150% power cut off the output, after the load is normal, the output is restored
Shock resistance: 10-500hz, 2G, 10min / 1 cycle, 60 minutes, each axis
Output ripple: <= 150MV
Working temperature: -10°C to 50°C, 20% - 90% RH (not coagulate frost)
Weight: 1.45 kg
Power supply size: 260 x 105 x 65mm (L * W * H)
Package includes:
1 x Power supply
