Specifications:
Input: 8V-40V
Output: 5V/8A
Efficiency: 95% (MAX)
Module size: 68mm*62mm*30mm
Working temperature: -40°C-+85°C
Protection: reverse connection protection, over current protection, over temperature protection.
Load capacity: 8A
Wiring method: DC5.5/2.1, terminal block free soldering
Scope of application: USB5V powered devices such as mobile power, mobile phones, tablets, recorders, etc.
Accessories: 6USB module, input DC line (length 30cm, red positive black negative)
Note:
1. If you are using a battery or a battery, the fully charged voltage must not be higher than the module's maximum input voltage.
2. This module has a single USB maximum current of 3A. The charging current of the mobile phone is generally 1-2A (except for fast charging). If your device's own charging current is only 1A, you can charge it with a large current, which is only 1A. The higher the current, the faster the charging, which is related to the charging current of your own device.
Package Included:
1 x 10V 12V 24V 36V To 5V/8A 6 USB Output DC-DC Buck Regulator
1 x Cable
