Product Features
1. Real time monitoring tire pressure and temperature.
2. Display show pressure of 4 tires on the screen all tires shown.
3. Display show which tire is abnormal.
4. Powerful function includes low pressure, high pressure, leakage, high temperature alarm.
5. Tire pressure and tire temperature can be switched by one key.
6. Alarm with beep sound and display screen red light flashing.
7. Sensor battery changeable.
8. With USB 2.0 power supply output: DC 5V, 2A.
Alarm Function
1. Leakage alarm
2. Low pressure alarm: The pressure is lower than 2.6Psi
3. High Pressure Alarm: The pressure is higher than 46Psi
4. High temperature alarm: The temperature of tire is over 65 degree Celsius
5. Sensor disabled alarm
6. Sensor battery run out of power alarm
Technical Parameter
1. Display
- Input Voltage: 12+/-3V
- Static Current: < 35 mA
- Operating Temperature: -40 ~ +85 degree Celsius
- Operating Humidity: 5~98%
2. Sensor
- Sensor Weight: <10g
- Pressure Range: 0Psi-51Psi / 0Bar-3.5Bar
- Battery Model: CR1632
- Battery Lifetime: >3 years
- Static Current: < 0.7uA
- Operating Current: < 12mA
- Operating Temperature: -40 ~+125 degree Celsius
- Pressure Error: +/-1Psi / +/-0.1Bar
- Temperature Reading Accuracy: +/-2 degree Celsius
- Operating Humidity: 5~98%
