Parameters:
Main control chip: STM32F103VET6
Working voltage: DC 8~36V
Working current: 58mA
Operating environment: a 20~65C
Storage temperature: -30~80C
Dimensions: 156*88*24mm
Product weight: 198g
Features:
1. Support 9 kinds of standard protocols of 0BD II/EOBD.
2. Support 0BD function such as vehicle diagnosis and real-time data flow.
3. with data waveform display, data storage and playback functions.
4. Data with emission detection.
5. color LCD display, high resolution.
6. the reliability is good, the power supply voltage range is 836V, with stronger overcurrent and overvoltage protection functions.
Supported Agreements:
◆SAE J1850 PWM (41. 6 Kbaud)
◆SAE J1850 VPW (10. 4 Kbaud)
◆ISO 9141-2 (5 baud init, 10.4 Kbaud)
◆ISO 14230-4 KWP (5 baud init, 10. 4 Kbaud)
◆ISO 14230-4 KWP (fast init, 10. 4 Kbaud)
◆ISO 15765-4 CAN (11bit ID, 500 Kbaud)
◆ISO 15765- 4 CAN (29bit ID, 500 Kbaud)
◆ISO 15765-4 CAN (11bit ID, 2500 Kbaud)
◆ISO 15765-4 CAN (29bit ID, 250 Kbaud)
Supported Vehicle Data:
1.read the error diagnosis code
2.Clear the original ceramic code (clear the error code and turn off the MIL)
3.engine revolutions per minute (RPMO)
4.calculated load value
5.coolant temperature
6.fuel system status
7.speed
8.short-term fuel situation
9.long-term fuel situation
10.intake manifold pressure
11.injection advance time
12.intake air temperature
13.air flow speed
14.throttle absolute position
15.oxygen detection voltage associated with short-term fuel state
16.fuel system status
17.fuel pressure
18.fuel consumption t monitoring, etc.
Remarks:
The number of data items supported by the model year is also different, subject to actual support.
