Description:Relative humidity adjustment,With change-over contact,High sensitivity,Easy to operate,Rail mountingApplications: Cabinet heaters, digital thermometer thermostats, mechanical thermostats, hygrostat thermostats, cabinet fans, breeding temperatures, Din heaters, Msr 3, fans with thermostats, grill temperature control, flat panel heaters, Ringder thermostatFeature:1. Adjustable relative humidity: the black knob is an adjustment switch that can adjust the humidity of 40%-90%;
2. High-quality flame-retardant casing: plastic UL94 standard V-0 fire rating, durable;
3. Easy installation: the rail is installed and can be fixed in the cabinet by using the conventional rail card;
4. Easy to operate: 4 wiring holes can carry 10A current, and can also carry heater and cooling fan.
Speciofication:
Brand:Minleaf
| Switch difference |
4% RH(±3% tolerance) |
| Humidity range |
40%-90% |
| Air velocity |
15m/sec |
| Contact type |
Conversion contact change-over contact |
| Contact resistance |
<10mΩ |
| Service life |
>100000 cycles |
| Switch minimum capacity |
20V AC/DC 100mA |
| Switch maximum capacity |
250V AC 5A DC 20W |
| EMC |
Acc.to EN 55014-1-2,EN 61000-3-2,EN 61000-3-3 |
| Wiring |
3-pole terminal block 2.5mm2 wire |
| Installation method |
35mm DIN Rail |
| Housing material |
Plastic UL94 standard V-0 fireproof rating |
| Installation size |
67*50*38mm |
| Weight |
Approx.60g |
| Operating/storage temperature |
0 to +60℃/-20 to +80℃ |
| Protection level |
IP20 |
Package included:
1XTemperature Controller Switch
