Product Usage:
►This three-phase brushless motor is suitable for --- high-end hand dryers, emergency medical ventilators, cushions for air, dust and dust.
Product advantages:
►High pressure (full pressure 12KPA), large air volume (520 liters / minute), low noise (distance from 1M far from 44dB to 1KPa), long life (4 hours of operation, 30 hours of life of up to 25,000 hours), high efficiency , high speed, high stability and so on.
This brushless fan has stable start, small size, low noise, low temperature rise, long service life, high efficiency, accurate accuracy, energy saving and environmentally friendly materials.
Note:
This blower requires a drive to function properly.
Technical parameters:
WM7060-12V
| Project |
Unit |
WM7060-12V |
| Voltage |
V |
12V |
| Max Speed |
rpm |
35000+/-5% |
| Max Current |
A |
15 |
| Max airflow |
L/min |
520 |
| Max air pressure |
KPa |
11 |
| Coil connection method |
|
“Y” |
| Max Power |
W |
190 |
| Size |
mm |
D:86mm, H:65mm |
| Weight |
g |
450 |
| Holzer angle |
degree |
120 |
| Bearing |
|
NSK double balls bearing |
| Rotor magnet pole number |
|
2 |
| Noise |
db(A) |
45(1M-1KPa) |
| Speed adjustment |
|
0-5V Or PWM |
WM7060-24V
| Project |
Unit |
WM7060-24V |
| Voltage |
V |
24V |
| Max Speed |
rpm |
36000+/-5% |
| Max Current |
A |
8 |
| Max airflow |
L/min |
520 |
| Max air pressure |
KPa |
12 |
| Coil connection method |
|
“Y” |
| Max Power |
W |
190 |
| Size |
mm |
D:86mm, H:65mm |
| Weight |
g |
450 |
| Holzer angle |
degree |
120 |
| Bearing |
|
NSK double balls bearing |
| Rotor magnet pole number |
|
2 |
| Noise |
db(A) |
45(1M-1KPa) |
| Speed adjustment |
|
0-5V Or PWM |
Package Included:
1 x High Pressure Blower(without drive)
Or
1XDrive
