Cooling and heating mode can be set through the menu. Can be used for domestic freezer, water tanks, refrigerator, industrial chiller, bolier, steamer, industrial equipments and other temperature-controlled systems.
For example:
1. You need control the temperature to 96°F. If the temperature drop to 94°F, you wants to start you heating device automatically: You can choose "Heat mode"(Set "HC" to "H"), set controlled value to 96°F and set "d" value, when the temperature drops to 94°F, your heating device will be started. When the temperature reaches 96°F, your heating device will be shut down. 2. You need control the temperature to 95°F. If the temperature rises to 99°F, you wants to start you cooling device automatically: You can choose "Cool mode"(Set "HC" to "C"), set controlled value to 95°F and set "d" value, when the temperature rises to 99°F, your cooling device will be started. When the temperature reaches 95°F, your cooling device will be shut down.
Specification:
Size: 85(L) x 46(W) x 25(H) (mm) Sensor cable length: 1 M (include the probe) Power supply: DC 12V Control range: 20℉ to 212℉ Control limit range (Relative to control value): 1℉ to 15℉ Resolution: 1℉ (It can not be used to control the temperature like "90.3℉", only be set as "90℉" or "91℉") Accuracy: ±0.5℉ Sensor mode: NTC (10K/3435) Power consumption: less than 3W Working temperature: 14℉ to 140℉ Relay contact capacity: MAX 10A Data retention: Yes
Package includes:
1 x Temperature controller with 3m NTC 10k sensor cable 1 x English Manual
